HTL Machines
Mumbai-Based Manufacturing Company for HTL Machines
FOILYGOO is a trusted Mumbai-based manufacturer specializing in high-performance HTL machines designed for precision, durability, and efficiency. With advanced manufacturing facilities and industry expertise, we deliver reliable solutions tailored to industrial printing and labeling requirements.
Our Machines & Attachments
We manufacture and supply:
- HTL Applicator Machines
- Foil Cutting Machines
- Zig Attachments
- Heater Attachments
- Special Purpose Machines customized as per client requirements
Each machine is engineered with high-quality components to ensure smooth operation, consistent output, and long-term performance.
Industries We Serve
Paint industries
Machine for paint buckets from 1 to 20 lit and above machine is plc based semi automatic sensor based foil winding. Auto ejection and zig adjustment in 6 direction makes it unique from other machine available in market.
Household
Bathroom set and kitchen set. Htl machine for house hold articles like container from 250gm to 20 lit bucket, tub, mug, jug, soap case etc. Machine is loaded with some unique features like flat and round printing, wrinkle free printing.
Modular switch
Chrome bordering semi auto machine with safty slider for modular switch border printing. 2 varient is available timer and plc based. 1 to 18 modular can be done.
MODEL NO - FGP4S
Semi-automatic plc-based machine specially designed for round articles along with foil tensioning system and auto foil winding.
Manual adjustment for tapper article with yaxis slider, manually adjustable height of machine to achieve different sizes of printing, each and every part is well coated material we are using 16mm ms base plate, 12mm ms plate for other use, 25mm dia rod (foil guide rod), 25mm dia ss rod.
(Cylinder guide rod)
German made heaters, DELTA PLC and HMI,
For pneumatics we are using JANATICS and Festo
Extra attachments:- Auto ejection, mark sensor, auto suction of article
MODEL NO - FGR15
SPECIFICATION
Semi-automatic plc-based machine specially designed for round articles along with foil tensioning system and auto foil winding.
manual adjustment for tapper article with yaxis slider, manually adjustable height of machine to achieve different sizes of printing, each and every part is well coated
material we are using 16mm ms base plate, 12mm ms plate for other use, 25mm dia rod (foil guide rod), 25mm dia ss rod.
(Cylinder guide rod)
German made heaters, DELTA PLC and HMI,
For pneumatics we are using JANATICS and Festo
Extra attachments:- Auto ejection, mark sensor, auto suction of article
MODEL NO - FGS15
SPECIFICATION
Semi-automatic plc-based machine specially designed for modular switches.
From 1 to 18 modular switches can be done.
Machines consist with one safety slider and sensor-based foil winding system and one main pneumatic cylinder attached to printing head; foil winding system is designed to reduce foil wastage.
x and y axis slider to match article and dies
Material used – 3mm Square pipe for Tabel, 16mm MS plate, 12mm MS plate, 25mm dia SS rod for cylinder guide, 25mm dia MS rod for foil guide.
Pneumatics – JANATICS, Timer and Temperature controller – Select
plc and HMI – DELTA
MODEL NO - FGF150C
SPECIFICATION
Semi-automatic timer-based machine specially designed for flat and round cosmetic articles along with foil tensioning system and auto foil winding.
manual adjustment for tapper article with y and x axis slider, manually adjustable height of machine to achieve different sizes of printing, each and every part is well coated
material we are using 16mm ms base plate, 12mm ms plate for other use, 25mm dia rod (foil guide rod), 25mm dia ss rod. (Cylinder guide rod)
catrage heater 4nos
For pneumatics we are using JANATICS and Festo
Extra attachments:- Auto ejection, mark sensor, auto suction of article
Why Choose Us?
We are committed to delivering efficient, cost-effective, and advanced HTL machine solutions that meet modern industrial standards.
Timely delivery backed by reliable after-sales service and technical support.
- Precision-engineered manufacturing
- Customized machine solutions
- Strong technical support
- Quality-tested products
- Industry-leading innovation
